Zipper Pouch Packing Machine Resealable Zipper Bag Packaging Line
| МОК: | 1 |
| Цена: | Negotiations |
| Стандартная упаковка: | Международная стандартная упаковка для доставки |
| Срок доставки: | 30 дней |
| Метод оплаты: | Л/К, Т/Т, западное соединение |
| Пропускная способность: | 300 комплектов в год |
Подробная информация
Место происхождения
Шанхай
Фирменное наименование
Waylead
Сертификация
/
Номер модели
WG-250
Документ
Скорость упаковки:
≦70 пакетов/мин
Размер сумки:
Длина: ≦400 мм, ширина: 130-260 мм.
Материал пленки:
Плоские пакеты, пакеты-стойки, пакеты на молнии, пакеты из композитной пленки и другие типы.
Источник питания:
380В
Расход воздуха:
5-7 кг/см2; 0,4м3/мин
Тип мощности:
Электрический
Потребляемая мощность:
8 кВт
Материал:
Стианлесс сталь
Ассортимент упаковки:
Гранулы Порошок Жидкость
Описание продукта
This zipper pouch packing machine focuses on the packaging of resealable zipper bags, with a specially designed zipper heat-pressing and sealing mechanism. It can accurately complete the zipper alignment and heat sealing process, ensuring the zipper is smooth and the sealing performance is reliable, which effectively extends the shelf life of packaged products. The machine supports non-stop bag type switching, and it can quickly adjust to produce zipper pouches of different capacities from 100g to 5kg. The body structure is sturdy and durable, with few wearing parts, which greatly reduces the later maintenance cost. It is widely suitable for packaging nuts, snacks, dried fruits and other products that need repeated sealing. We provide complete spare parts supply service, and many users in Ghana, Indonesia and other regions have achieved good production efficiency improvement after using this machine.
Technical Specifications
| Model | WG-210 | WG-250 | WG-300 |
|---|---|---|---|
| Bag Size | Length: 120-380mm Width: 90-210mm |
Length: ≤400mm Width: 130-260mm |
Length: ≤400mm Width: 160-300mm |
| Packing Speed | ≤70 bags/min | ≤70 bags/min | ≤65 bags/min |
| Work Stations | 8 | 8 | 8 |
| Packaging Formats | Flat bags, stand-up pouches, zipper bags, composite film pouches | Flat bags, stand-up pouches, zipper bags, composite film pouches | Flat bags, stand-up pouches, zipper bags, composite film pouches |
| Power Supply | 380V | 380V | 380V |
| Total Power | 8Kw | 8Kw | 8Kw |
| Air Consumption | 5-7kg/cm²; 0.4m³/min | 5-7kg/cm²; 0.4m³/min | 5-7kg/cm²; 0.4m³/min |
| Film Material | Single PE, PE composite film, paper film, various composite films | Single PE, PE composite film, paper film, various composite films | Single PE, PE composite film, paper film, various composite films |
| Machine Weight | 500kg | 580kg | 850kg |
| Machine Dimensions | 1700*1140*1470 mm | 1850*1250*1520 mm | 2100*1500*1520 mm |
Application Range
Block Items
Candy, chocolate, rock candy, biscuits, pastries, peanuts, green beans, pistachios, nuts, cooked food, pickles, puffed foods, daily necessitiesParticles
MSG, chicken essence, sugar, melon seeds, nuts, capsules, granular medicines, seeds, feed, pesticides, fertilizers, chemical raw materialsPowders
Condiments, monosodium glutamate, salt, glucose, refined sugar, milk powder, washing powder, pesticides, fertilizers, chemical raw materialsLiquids
Rice wine, soy sauce, rice vinegar, juice, beverages, detergentsSauces
Tomato sauce, peanut butter, jam, chili sauce, bean pasteOther Materials
Various other products suitable for bagging Advantage Features
- Designed in accordance with GMP standards and CE certified
- Full servo control system for reliable, fast, and precise operation
- Empty bag tracking and monitoring device prevents sealing without bag opening, saving packaging materials
- Eight-station structure with centralized control via programmable PLC and six flat touch screens for simple operation
Complete Packaging Machine Range
Shanghai Waylead Intelligent Technology Co.,Ltd. is specialized in turn-key solutions for packaging processing projects and fruit/vegetable processing lines. The company focuses on packaging equipment, robot applications, fruit and vegetable processing equipment, etc., and is committed to the fruit and vegetable processing industry, baking industry, snack food industry, freeze-drying industry, and powder industry. sauce industry, hardware chemical industry and other one-stop professional services.
Our comprehensive packaging solutions include VFFS machines, flow wrapping machines, heat shrink packaging, pouch packing machines, and complete automated packaging lines with weight inspection, metal detection, carton packing, sealing, coding, and palletizing systems.
Frequently Asked Questions
Are you a trading company or a manufacturer?
We are a manufacturer, providing quality products at factory price. Welcome to visit us!
What quality guarantee or warranty do you provide?
We provide high-quality machines with a 3-year warranty and lifetime technical support.
When can I get the machine after payment?
Delivery time depends on the specific machine model ordered.
How do you provide technical support?
24/7 support via phone, email, or messaging platforms; installation guides and videos; overseas engineering services available.
How does your after-sales service work?
Machines are pre-adjusted before shipment with free training available. Lifetime technical support provided via multiple communication channels.
How about spare parts?
We provide a comprehensive spare parts list for reference.
Can you help with custom design requirements?
Customized design available with our experienced mechanical engineers.
Can you help analyze and design machines for new product samples?
Yes, our technical department can analyze, design, and test new products you provide.
How do I start an order?
30% deposit after signing contract, production arrangement, pre-shipment testing and inspection, balance payment before shipment.
Can you send product catalog and price list?
Electronic catalog available. Please consult us for specific product pricing.
Can I visit your factory?
Yes, welcome to visit our factory at Room 304, Wanchuangfang, No.155 Anzhi Road, Jiading District, Shanghai, China.
Contact Information
Room 304, Wanchuangfang, No.155 Anzhi Road, Jiading District, Shanghai, China
